Speed Restraint Within a 20mph Zone
To encourage adherence to the designed maximum speed of 20mph, it is necessary to implement one engineering measure drawn from lists (a) or (b) below in each 20mph zone. In many circumstances, it will also be necessary to implement a complementary measure drawn from list (c).
Measures to reduce visibility for the driver are not acceptable by themselves. Rumble strips are also not an adequate speed-restraint measure. Speed-restraint measures should be located at maximum intervals of 60m, starting within 50m of the entry junction or zone. They must be well-lit and must comply with the Highways (Traffic calming) and Highways (Road Hump) regulations. They may take the form of changes in horizontal alignment, changes in vertical alignment or complementary measures.
The visibility of a route can be agreed on a case-by-case basis, with the standard being applied to the geometry of the road.
(a) Changes in Horizontal Alignment
Bends
These should be tighter than the minimum specified for each street type, down to a minimum centreline bend radius of 7.5m. The deflection should be greater than 45 degrees with a mountable shoulder to enable larger vehicles to overrun.

a. Deflection greater than 45°
b. Centreline bend radius less than minimum specified for road type
c. Vehicle deterrent paving 1/36 slope into road
d. 15mm maximum upstand
Narrows
The narrowing of the carriageway to 2.7m for a length not exceeding 7m will cause drivers to wait for oncoming traffic to pass. A 500mm mountable shoulder either side will allow service vehicles to negotiate this obstruction. This measure is not appropriate for shared surfaces.

a. 15mm maximum upstand
b. 500mm vehicle deterrent paving at 1/36 slope into road
c. Change of surface material
d. Ramped narrows suitable for roads 5.5m or less in width
e. Ramped narrows suitable for roads 6m wide
f. Red and white posts and verge markers
g. Ramp
Chicanes
To be effective, the lateral displacement of the running lane must be at least 2m and the length of the displacement no greater than 10m. A reduction of carriageway width to 2m at the entrance and exit of the chicane is acceptable, but a mountable shoulder may be necessary to provide a 3.1m-wide path for service vehicles. This measure is not appropriate for shared surfaces.

a. Red and white posts and verge markers
b. Mountable shoulder in vehicle deterrent paving to provide 3.1m path for service providers
c. 2m width
d. Normal road width
e. Maximum length of displacement 10m
f. 6m taper
Islands
An island should result in a lateral displacement of the running lane of at least 2m. The island may be any shape, subject to the minimum dimensions given below. Mountable shoulders may be used to enable the passage of service vehicles, but no vehicle should be able to overrun the centre of the island. This measure is not appropriate for shared surfaces.

a. Low shrub planting
b. 7.1m radius
c. 2m radius
d. 20m radius
e. Upstand to prevent vehicle overrunning
f. Mountable shoulders in vehicle deterrent paving to provide a 2.1m path for service vehicles overrun
g. Normal road width
(b) Changes in Vertical Alignment
Humps
Round-topped humps should be 75mm high and no longer than 3.7m. They are not appropriate for bus routes, shared surfaces or street types A, B or C.
Cushions
On street types C and D, which are likely to be used by buses and emergency services, speed cushions should be used instead of humps. They are designed to allow the wheels of buses and wide-wheelbase vehicles to pass either side of the raised area while cars still have to negotiate the hump. They should be constructed in pairs.
Ramps
Single or successive ramps 75mm in height are appropriate within or at the entrances to shared-surface areas.

(Top) Successive 50mm ramps for shared surfaces (Bottom) Single 100mm ramp for shared surfaces
a. 50mm rise
b. 100mm rise
Speed Tables
A plateau may be created by ramps rising 75mm at a rise of 1-in-12. Unless there is a junction, such a plateau should be no longer than 7m – but where it is to be used by public transport vehicles, it should be 12m in length with a rise of 1-in-15. Tactile surfaces should demarcate the border between carriageway and footway for the benefit of the visually impaired. This may be a good way of slowing traffic for a footpath crossing.

(Left) Plan view (Right) Section along road
a. Single 100mm ramp for shard surfaces
b. 600-1200mm
c. Tactile surface to footway, 50mm minimum upstand from this table
d. 7m maximum where there is no junction
e. Surface material different from the rest of the road
Table Junction
A junction may be treated as a plateau approached by ramps as described in the Speed Tables section of this guide. Tactile surfaces should demarcate the boundary between carriageway and footway.

a. 600-1200mm ramp
b. Surface material different to the rest of the road
c. 100mm above normal road level
(c) Complementary Measures
Buildings
Buildings may form an end-stop to a straight stretch of street, or be angled indicating a change of direction. They may also form a gateway through which the street passes. Used in conjunction with other speed restraints, they can induce drivers to reduce speed and take extra care.
Page updated: 15/02/2018
